April 2021 World Cement

DAVID BIZLEY, EDITOR

pring has finally sprung. The trees are lined with blossom, daffodils and tulips have sprouted from seemingly every spare patch of earth, bumblebees are bumbling, I’m buying up hay fever medication, and it’s just a few more days until Easter (and a four-day Bank Holiday weekend for those of us in the UK). But it’s not just the flowers that are opening up. Spurred on by declining case numbers and the success of the vaccine rollout (so far…), the UK is gradually rolling back pandemic restrictions once more. On the day that I write this, in England two households (in groups of up to six people) are once again allowed to meet outdoors (albeit with social distancing), weddings (attended by six people) are back on, and outdoor sports facilities, such as tennis courts and golf courses are reopening. We aren’t out of the woods yet; case numbers are rising elsewhere, and with the risk posed by novel variants of the virus, nowhere is completely safe until everyone has been vaccinated, but there is finally some steady light at the end of the tunnel and we now have the tools to fight back. That means that it’s once again time to think about how we want the world to be when life returns to ‘normal’ in the not too distant future. For example, the sudden change in lifestyles imposed by the pandemic has accelerated the trend towards remote working and left many businesses with decisions as to how much they support it once restrictions are lifted. The other big factor is the environment. Although industrial activity has recovered somewhat since, the initial lockdowns in 2020 provided, for the first time, a live ‘before & after’ snapshot of what the world would be like with fewer emissions, less vehicle traffic, noise, and other ‘side effects’ of our industrialised societies. The stories of wildlife reclaiming quiet streets and news of the drop in emissions were heart-warming and a sign that making ‘green’ choices really did have an impact. That’s why it’s more important than ever that you attend EnivroTech 2021, the interactive online conference hosted by World Cement that focuses on what the cement industry can do to reduce its environmental impact. Set over two days (20 & 21 April), EnviroTech 2021 will feature technical presentations packed with actionable business insights from industry leaders, such as LafargeHolcim, FLSmidth, Votorantim Cimentos, Beumer Group, thyssenkrupp Industrial Solutions and many more. In addition to presentations, we’ll also be running live Q&As so you can put your questions directly to the experts. And if that wasn’t enough, we’ll also be hosting a virtual exhibition, so you can interact with company representatives and check out the latest products, projects and services on offer from a range of leading companies. Simply head over to: www.worldcement.com/envirotech2021 to register, free of charge. I look forward to seeing you there.

80 years of experience lead us here. And, we’re just getting started

ADDITIVE INTELLIGENCE

GCP DashSM business intelligence platform, optimizes product selection for cement producers, resulting in operational savings, faster ROI and more sustainable cement production.

Find out how we can help you revolutionize production. Visit gcpat.com

For 80+ years our industry experts have helped cement producers optimize their products and gain new business opportunities. GCP DASHSM additive intelligence platform is built on proprietary algorithms to construct a customized model for each cement and recommend the correct product faster.

NEWS Axians IAS completes ‘unique’ project with HeidelbergCement “An exceptionally good cooperation and an outstandingly good result.” Those were Alexander Müller’s closing words when HeidelbergCement AG put its new Logistic Portal into operation. Alexander is the responsible and leading IAS team member for the entire VAS® roll out project for the Heidelberg Sand and Gravel works in Germany. Together with the senior HC staff member in charge, the entire roll out team put together a unique project. Especially in times of COVID 19, the launch of a powerful and centralised logistics solution meant a well thought out and planned execution of the project was necessary. The initial logistics portal created specifically for HeidelbergCement AG went live back in 2015. The project team at that time had created an unprecedented online tool that revolutionised the entire ordering process in the bulk materials industry. The project offered several advantages for customers. With the further development of the portal and the new challenges the project team had to face in 2020, they outperformed their former performance many times over. The team had to deal with three areas in particular: f Optimisation of automation processes especially for sand and gravel for shorter gate to gate times. f Development and implementation of a special ‘all in one’ mask for faster manual handling of trucks. f Development and implementation of a wheel loader application for the online and off-line case. One of the top priorities in the project was to integrate the three challenges mentioned above into the software solution in the best possible way. Another priority was the harmonious integration, successful synchronisation and synergy utilisation of the two divisions, cement and aggregates. This was achieved by means of a VAS template.

April 2021 World Cement

Due to restrictions on handling in 2020, the project team had to deal thoroughly with the following challenge: “How can we take all sand and gravel plants into operation without being on site whilst guaranteeing that everything runs well at the end?” As part of the further digitisation and optimisation of HeidelbergCement AG, an integrated material flow management system will be introduced to achieve significant savings in logistics costs throughout the group. Based on the existing development process, HeidebergCement AG was able to provide remote access, which enabled all plants to go live smoothly. Various plants worldwide in the cement, aggregates (sand & gravel) and cement business areas are currently being equipped with the VAS solution from Axians IAS GmbH.

UltraTech chooses AUMUND India as equipment supplier for ‘Project Spring’ expansion UltraTech has chosen AUMUND India to supply a comprehensive equipment package comprising 22 chain bucket elevators, 46 belt bucket elevators, six pan conveyors and 11 Samson® material feeders for its ‘Project Spring’ expansion. The order is one of the largest to date for AUMUND India. The expansion project includes three integrated cement production units, each with capacities of up to 10 000 tpd. For these kiln lines, AUMUND India will supply the critical clinker cooler extraction conveyors, well known for their reliability and availability, as well as the transfer conveyors to the clinker silos. In addition to the clinker production lines in Madhya Pradesh, Rajasthan and Chhattisgarh, six cement grinding plants in various locations in India are part of the capacity expansion plans. The order won by AUMUND India includes raw material handling bucket elevators, critical kiln feed bucket elevators with heights up to 157 m, and roller press recirculation bucket elevators with capacities up to 2200 tph, as well as clinker and cement handling bucket elevators of various sizes. At the end of 2020, UltraTech decided to increase its current consolidated production

NEWS DIARY Hannover Messe - Digital Edition 12 – 16 April, 2021 Hannover, Germany www.hannovermesse.de

20 – 21 April, 2021 An interactive online conference focusing on reducing the cement industry’s environmental footprint. For more information, or to register for free, head over to: www.worldcement.com/ envirotech2021

IEEE-IAS/PCA Cement Conference 2021 24 – 28 May, 2021 www.cementconference.org

16 – 17 June, 2021 www.worldcement.com/ optimisation2021

BULKEX21 12 – 13 October, 2021 Chesford Grange, Warwickshire, UK secretary@mhea.co.uk www.mhea.co.uk

capacity of 116.8 million tpy by 12.8 million tpy with a mix of brownfield and greenfield expansions in the eastern, central and northern parts of India. The completion of these capacity additions will further reinforce the position of UltraTech as the third largest cement producer in the world outside of China.

Starlinger bags fit the national standard for cement packaging in China As China is modernising its cement production, the government has also set up a national standard, defining types and specifications of bags used for packaging cement. One of the three bag types permitted in the Chinese Standard GB/T 9774-2020 ‘Sacks for Packing Cement’, which was officially released in October 2020, are block bottom valve bags made of woven polypropylene tape fabric. This type of bag was invented in 1995 by the Austrian engineering company Starlinger & Co. GmbH and patented under the brand name AD*STAR. With the AD*STAR bag, Starlinger, specialised in machinery for woven plastic packaging, created a sustainable and efficient packaging solution for cement and all kinds of dry bulk goods. The idea behind it was to combine the advantages of a paper bag – its brick shape and suitability for automatic handling – with the tightness and flexibility of a PE film bag, and the strength and resistance of a woven PP bag. The result: A laminated one-layer block bottom valve bag made of stretched and woven polypropylene tapes. The main assets of AD*STAR bags are their extremely low breakage rate and excellent protection against moisture. Especially in countries like China, transport and storage of cement in bags is widespread and involves a lot of transhipping and long-term storage. Loss of cement due to bag rupture or hardening in humid conditions is a big issue. Packaging cement in AD*STAR bags offers substantial savings potential in this respect: low breakage rates and good moisture protection mean that significantly less cement is lost in the logistic chain. Consequently, not only environmental pollution is reduced, but also less cement needs to be produced to replace these losses, which in turn saves CO2 emissions. An independent Life Cycle Analysis carried out in 2015 showed that due to these characteristics, AD*STAR cement bags have lower global warming potential than multi-layer paper cement bags and are currently the most environmentally friendly packaging for cement. AD*STAR bags are produced on Starlinger ad*starKON block bottom conversion lines and are available in a wide range of sizes. The company’s focus on research and development ensures that AD*STAR bags and AD*STAR production technologies are continuously improved and adapted to the needs of the market. Technological advancements and new product features such as easy-open closure or handles for carrying make the bags even more versatile and usable in different applications.

World Cement April 2021

NEWS Currently, around 15.7 billion AD*STAR sacks are produced each year on more than 550 Starlinger conversion lines installed on five continents. The new Chinese Standard for cement packaging applies to cement bags holding up to 50 kg and lists the above mentioned laminated woven plastic bags (made of one layer of laminated plastic fabric or with additional paper liner), paper bags (three-layer, three-layer with PE liner, four-layer bags), as well as paper-plastic composite bags (paper bags with plastic liner) as possible packaging options. All three types of bags must be designed as block bottom valve bags. The standard specifies the dimensions as well as physical and mechanical requirements of the cement bags. Regarding break resistance, for example, a cement bag has to survive a drop from a 1 m height a minimum of six times before it breaks. Furthermore, printing and marking, general bag appearance, testing methods, and rules for quality inspection during bag manufacture are established in the standard. It also stipulates that each bag must be provided with a certificate before selling. By recommending woven polypropylene block bottom bags in the new National Standard, the Chinese government has adopted a future-oriented approach that aims for more sustainability in the cement industry. It curbs unnecessary loss of cement during production, transport and storage, reduces environmental impacts, improves working conditions for operators on the cement filling lines, and generally makes the handling of cement in 50kg or smaller units more efficient. It also means that the formerly widely used sewn woven plastic bags which were irregular in shape, often leaking, and problematic for automatic filling and handling, will no longer be permitted as cement packaging in China. Cement companies are given a transition period until 31 March 2022 to adapt to the new standard. Due to this time limit, Starlinger’s AD*STAR conversion lines are currently high in demand in China. The company expects to deliver and install machines for an additional production capacity of more than 2 billion AD*STAR bags on the Chinese market in 2021 and 2022. 8

IKN makes progress on Kiln Line No. 8 for Märker Cement New projects always begin with a first step. When looking at the construction site at Märker Cement, the first series of steps is already quite visible. Both the solid concrete basis for the preheater and the first kiln pier have almost reached their full heights. Foundation works for the cooler building are in progress, showing the future footprint. The new kiln line No. 8 is being built right next to the existing production line which it will replace after commissioning. The start of this important project directly in the heart of Germany and during the difficult COVID-19 times shows the commitment of Märker Cement towards the plant, its employees, and the region.

Cimprogetti receives orders for multiple lime hydration plants Italy-based engineering firm, Cimprogetti, which supplies vertical kilns for the calcination of limestone and dolomite and complete quicklime hydration units, has received several orders for hydration plants. Rheinkalk, a subsidiary of Belgium’s Lhoist, has placed an order to Cimprogetti for two hydration plants with a 10 tph nominal capacity for its lime plants at Regensburg (Walhalla plant) and Efringen-Kirchen (Istein plant). The Walhalla Plant features a CIM-HYDRAX-4G hydrator mod, the fourth generation of Cimprogetti hydrator, with a customised filter. The Istein Plant features instead the CIM-HYDRAX-4G MAX hydrator mod, with an independent premixing stage. The hydration plants have been ordered as part of a renovation programme. Cimprogetti also received an order from a leading Chinese Group for a 10 tph hydrating plant featuring the 5-shaft hydrator Cim-Hyrdax-TG-600. The calcium hydroxide will be used as absorbent for the FGD device located in Haimen Port area (Jiangsu Province). The use of Ca(OH)2 sorbent allows for a reduction in the concentration of acid gases in different industrial sectors; average of 15 – 30% for HCl, 50 – 90% for SO2 and 80% for HF in certain process conditions (temperature and pressure). World Cement April 2021

DON’T GET TRAPPED Analysis Complete, Replace PowerCore® Today

BHA TotalPleat ®

- Long Filter Life - Energy Savings - Low Pressure Drop

The deep-pleat design of the BHA® TotalPleat™ filter has larger airflow passages with 92% of the filter face open to flow, allowing for full dust ejection during cleaning. Dust doesn’t get trapped in TotalPleat airflow passages, operates at a lower pressure drop, giving longer useful filter life as reported by customers.

www.parker.com/totalpleat

Powercore is a registered trademark of Donaldson Company, Inc. ®

Wang Lan, China Building Materials Academy, discusses the installation and operation of a moderate temperature SCR Reactor for ChangXing Southern Cement Company.

EVERYTHING IN

MODERATION T

he high temperatures in rotary cement kilns result predominately in the formation of NOx. Without emissions control measures, the NOx concentrations in the flue gas of rotary kilns are in the range of 800 to 1800 mg/m3. In China, there are about 1650 cement production lines, producing around 2.4 billion t of cement and 1.55 billion t of clinker in 2020. Calculated with the emission

coefficient of 1.80 kg/t clinker, the yield of NOx is about 2.8 million t from the cement industry. This emission source is ranked third largest after the electrical power and transportation sectors in China. NOx is a severe air pollutant, and can lead to the formation of acid rain while also causing harm to human health. DeNOx is a top priority mission for the sustainable development of the cement industry.

China’s Cement Industry Emission Standard of Air Pollutants (GB4815-2013) set up limitation values for NOx emissions at 320 mg/m3 and 400 mg/m3 from cement kilns in different areas. However, several local governments have issued more stringent requirements, outlining that NOx emissions from cement kilns must be below 50 mg/m3 and NH3 slip below 5 mg/m3 if ammonia is used as reducing agent. The best available technologies for DeNOx operations include primary measures and secondary measures. The former are based on the principle of reducing the excess oxygen levels and the peak flame temperature in cement kilns, for example by using a low nitrogen burner and staged combustion. However, the DeNOx efficiency of the primary measures cannot exceed 50% without interfering with cement kiln operation. The latter includes SNCR (selective non catalytic reduction) and SCR (selective catalytic reduction)

technologies, and they often use ammonia or other nitrogen-containing compounds with the chemical reaction: NH3 + NOx → N2 + H2O. Usually, DeNOx efficiency of SNCR is controlled at 60%, otherwise it could lead to more NH3 slip, e.g. high emissions of unreacted ammonia. Compared to SNCR, SCR can achieve DeNOx efficiency of up to 95% and it cause less NH3 slip, as the NH3 to NOx molar ratio can be controlled as 1:1. In order to limit NOx emissions to a low level of 50 mg/m3, the use of the SCR technique is necessary.

Development of a moderate temperature SCR technique

The key setup of the SCR technique involves a SCR reactor, which is a high tower with several layers of catalyst modules installed inside. Flue gas from the cement kiln mixed with injected ammonia is drawn into the reactor, where NH3 reacts with NOx quickly when passing through the channels of the Table 1. The parameters of the flue gas from the waste heat boiler. catalyst element (Figure 1). The temperature No. Item Data Unit Note of flue gas exiting 1 Flue gas 380 000 m3/hr 710 000 (WC) the top of the preheater is <4 % 2 O2 about 320ºC, 3 Temperature 200 - 220 ºC and the dust 4 SO2 < 300 mg/m3 O2 10% content of the flue gas is about O2 10% 5 NOx < 300 mg/m3 120 g/m3. When 3 O2 10% 6 Dust < 60 g/m exiting the waste 7 Moisture 4 % heat boiler, the temperature of the flue gas is reduced to about 200ºC, and the dust content is reduced to about 60 g/m3. The SCR reactors can be placed before the waste heat boiler (‘high temperature Figure 1. NH3 reacts with NOx quickly in the SCR reactor. configuration’) or after the waste heat boiler (‘moderate temperature configuration’). The ‘high temperature configuration’ can also be classified as a ‘high dust’ layout or a Figure 2. The layout of a moderate temperature SCR reactor. 12

World Cement April 2021

‘low dust’ layout. The ‘high dust’ layout has little effect on the efficiency of the waste heat boiler, but has a high impact on the service life of catalyst material and on the DeNOx efficiency of the SCR reactor. The ‘low dust’ layout requires a dust collector installed in front of the SCR reactor to lower the dust content of the flue gas to about 55 g/m3. This not only reduces the efficiency of the waste heat boiler significantly, but also complicates the SCR reactor system and increases the potential stoppage of the entire system. ‘Moderate temperature configuration’ refers to the SCR reactor being arranged between the high temperature fan and the raw material mill system, as shown in Figure 2. It has the advantages of both ‘high temperature’ layouts. This SCR reactor has no effect on the efficiency of the waste heat boiler. Due to the natural separation in the waste heat boiler, the presence of dust in the flue gas decreases from 120 g/m3 to 60 g/m3 before the flue gas enters the SCR reactor. Moderate temperatures will also result in a smaller volume of flue gas, thus allowing for smaller dimensions of the reactor, and in turn for lower construction investment and lower costs of the SCR reactor system. In order to develop moderate temperature SCR techniques, research has been

textile packaging l recycling

Figure 3. The semi-scale SCR reactor. conducted into the raising of DeNOx activity of the traditional SCR catalyst. Some strong absorptive materials have been added to the catalyst to reinforce its adsorption of NH3 and NOx. Trace transition metals, such as W2O5, have been added to the catalyst to promote its moderate temperature activity. After that, a semi-scale SCR reactor is installed with 3+1 catalyst for the examination of the function of the newly developed catalyst materials, as shown in Figure 3. In this semi-scale

l Let our experience work for you!

SCR reactor, each layer of catalyst has only one catalyst module. Flue gas of 10 000 m3/h from the cement kiln is drawn into the reactor and its

temperature and the dust content are 200ºC and 60 g/m3, respectively. The NOx concentration in the flue gas from the cement kiln has been detected as up to 300 mg/m3, and due to the unreacted ammonia of SNCR in kiln system, its NH3 content has also been tested up to 120 mg/m3. In this case, a certain amount of ammonia has been added and injected into the SCR reactor to maintain the molar ratio of NH3 to NOx of 1:1. The semi-scale SCR reactor has been in operation for nearly two years, with DeNOx efficiency up to 90%. Figure 4. The design of a moderate temperature SCR reactor. This research work has confirmed the feasibility of the moderate Table 2. Major equipment and setup of the SCR reactor. temperature SCR technique. No.

Equipment and setup

Reducing agent

Note

The initial storage tank of ammonia for SNCR was used and two new ammonia pumps were added. A new set of meters were added 2

Meter/jetting

Catalyst

Dust blowing

Compressor

and modules to control the dosage of ammonia were delivered. A new ammonia evaporator with 125% capacity was added. Four catalyst layers were installed, and a fifth layer was added as a backup. Rake teeth blowers and acoustic soot blowers with compressed air were used. Two new compressors were added, with one in operation and one on standby.

Connected ducts and pipes

New baffles were set up for original ducts and pipes.

Dust delivery

A screw feeder to star feeder was added below the dust bucket.

Electrical & controlling

Connections were made to the central control room and DCS system.

Application of the moderate temperature SCR technique ChangXing Southern Cement Company is located in the Zhejiang Province, Changxing county. The company owns a 6300 tpd cement clinker production line with a rotary kiln of Ф4.8 x 72 m, a TDF precalciner and a waste heat boiler. A breakdown of the flue gas from the waste heat boiler is listed in Table 1. The production line has been added with the SNCR system, using up 350 l/hr of ammonia (20% concentration), and reducing NOx emissions to about 280 mg/m3. Considering the stringent upcoming requirements to lower the emissions of NOx to less than World Cement April 2021

50 mg/m3 and NH3 slip to less than 5 mg/m3, the cement company decided to make use of SCR techniques – the moderate temperature configuration was chosen for the plant design. The designed SCR reactor (Figure 4) was placed after the waste heat boiler, with a section area of 64 m2, height of 34 m, and the whole tower of 350 t. Inside the SCR reactor, 4+1 catalyst layers were installed, and each layer has 48 modules. The whole volume of the catalyst used is about 200 m3. Around and above each catalyst layer, acoustic soot blowers and rack teeth blowers were fitted to avoid the accumulation of the dust on the catalyst layer and to help convey the dust to a hopper at the bottom of the reactor. CFD simulation analysis was conducted for the design of connected pipes to the reactor in order to optimise their arrangements. Deflectors were set up in suitable positions inside the pipes in order to improve the uniformity of the flue gas and to prevent the creation of deviant dust currents, as deviant dust currents may cause severe abrasion of the catalyst materials and block up the cells of the catalyst. The SCR reactor was equipped with meters and gauges to detect and measure the pressures, temperatures and compositions of the flue gas, and to send all this data to the newly added DCS system for remote monitoring and daily start-stop of the reactor. The SCR reactor was attached to the ammonia injection system and can perform DeNOx by itself. It can also utilise NH3 slip from the SNCR system to perform DeNOx. The economy of both operation methods is under review based on the DeNOx efficiency, the consumption of ammonia, the NH3 slip and the power consumption of the entire system. Major equipment and setups of the SCR reactor are listed in Table 2. The construction duration of the SCR reactor (Figure 5) took around 100 days and the kiln was shut down for a week to integrate the SCR reactor. Since then, it has been in steady operation alongside the kiln for nearly one year. The results of the long-term operation indicate that when operating with SNCR, the consumption of ammonia is 2.2 kg/t-clinker with NOx emissions of less than 40 mg/m3 and NH3 slip of less than 5 mg/m3; whereas when operating by SCR itself, the consumption of ammonia is 2.0 kg/t-clinker, with NOx emission less than 30 mg/m3 and NH3 slip less than 5 mg/m3. The pressure drops of the SCR reactor and entire SCR system are 320 Pa and 1100 Pa, respectively, and the power consumption of the entire SCR system is about 3 kWh/t-clinker, fully meeting the requirements of the plant design proposed by ChangXing Southern Cement Company. April 2021 World Cement

Figure 5. The moderate temperature SCR reactor tower.

Conclusions Controlling NOx emissions is one of the most important tasks for the cement industry to deal with, and achieving low emissions of less than 50 mg/m3 is the top priority of China’s cement industry for the near future. DeNOx techniques, such as low NOx burners, staged combustion and SNCR can reduce NOx emissions to a certain extent, but SCR carries out DeNOx operations much more efficiently. Compared to ‘high temperature configuration’, the ‘moderate temperature configuration’ technique offers some obvious advantages, such as low investment, low operation cost, and long-term steady operation. After nearly one year of operation of the full-scale ‘moderate temperature configuration’ the SCR reactor for ChangXing Southern Cement Company has confirmed its technical feasibility and low operation cost. This technique is imperative for China’s cement plants to realise their NOx ultra-low emissions and green development goals.

About the author Wang Lan is a professor at China Building Materials Academy, Chair of China Cement Engineering Technology Committee, and consultant for China Cement Association. The principal areas of research in which the author has worked are energy saving and emissions reduction of cement production, especially flue gas DeNOx with SCR technology. 15

The Ez Lift Suspended Platform is engineered to meet the highest international safety standards

INDUSTRY LEADING VERTICAL BRICK INSTALLATION Bricking Solutions Ez Lift Suspended Platform is the newest equipment for vertical brick work. The modular structure of high - strength aluminum components are designed to ƦƩƉǚŠĸĿ ĕ ȁĿǠŠıŷĿɆ žĕſĿǀǚĿƩĕıŷĿ ǛƉƩŴ ƦŷĕƺŔƉƩž ŔƉƩ ƦĿƩưƉſſĿŷ ĕſĸ ĿƨǀŠƦžĿſƺ Šſ ǚĿƩƺŠĲĕŷ ǚĿưưĿŷư ưǀĲŜ ĕư ŷŠžĿ ŴŠŷſưɆ ƦƩĿ ĲĕŷĲŠſĿƩưɆ ĲǡĲŷƉſĿưɆ PưĕžĿŷƺ ŔǀƩſĕĲĿưɆ ĕſĸ žƉƩĿɌ

www.brickingsolutions.com

SAFE DESCALING IN PREHEATER TOWER

BROKK DESCALER

When working with removal of refractory, castable or build-up, safety must always be the main concern. The Brokk Descaler allows for maintenance work without a single person entering the cyclone, calciner or any other area in the preheater tower. With the perfect combination of safety and accessibility ƉǀƩ ƩĿžƉƺĿɨĲƉſƺƩƉŷŷĿĸ ĸĿưĲĕŷĿƩ ƦƩƉǚŠĸĿ ĿǿŠĲŠĿſƺ ưƉŷǀƺŠƉſư ƺƉ ƩĿĸǀĲĿ Ʀŷĕſƺ shut down time. dĿĕƩſ žƉƩĿ ĕıƉǀƺ ưĕŔĿ ĕſĸ ĿǿŠĲŠĿſƺ ĸĿưĲĕŷŠſŕ ĕƺɅ www.brokk.com/descaler

BACK TO THE

GRIND WORLD CEMENT GRINDING Q&A

World Cement interviewed some of the leading equipment suppliers for their thoughts on the topic of grinding & milling. Read on to hear from: FLSmidth, Gebr. Pfeiffer, Loesche, and thyssenkrupp Industrial Solutions AG. 1) What do you see as the main challenges facing the grinding operations of cement manufacturers today? How can these be resolved? FLSmidth There are several challenges facing grinding operations in cement plants. First, enabling the use of new and different feed materials and/or making different cement products as part of sustainability initiatives creates operational challenges. Naturally, operating parameters

have to be adapted to the new materials – and sometimes there is more than one, or materials that have frequently changing properties. In addition to SCMs, there are alternative fuels and the impact they can have on clinker grindability and quality. Then there’s the challenge of whether or not existing equipment can cope with new materials without driving maintenance costs out of control. The need to manage operating and maintenance costs is a general challenge facing cement manufacturers independent of sustainability factors.

The first means of addressing these challenges is careful equipment selection. Whether evaluating the installation of a new mill or a system upgrade, it is critical to balance immediate needs with the likely impact of carbon reduction and sustainability initiatives in the near future. Small adjustments to sizing parameters with minimal effect on cost can have a significant impact on the flexibility to adapt to a broader range of materials. The second is the use of digital technology. Solutions focused on operations such as quality control or process control systems streamline the use of varying feed materials to minimise potential negative quality impacts and smooth operating conditions. Online condition monitoring services (CMS) enable predictive maintenance. This significantly improves system reliability in general and, more importantly, contributes to protecting equipment from mechanical failures and unexpected downtime while optimising for material changes. Gebr. Pfeiffer There are three main challenges: Sustainability, efficiency and digitisation. These are intrinsically linked. Sustainability has come to the forefront, quite rightly so, because our clients strive to (and are required to) improve their environmental performance and energy use. Efficiency is important for sustainability, as well as for the reduction of production costs. Digitisation feeds into the ease of use of the mill, as well as its process efficiency and, hence, sustainability. Our consistent product development is oriented towards the needs of our clients. Some achievements include: a 10% increase in power density of the current MVR series; increased specific dust load after the mill, which leads to a reduced gas volume flow in the plant; and lower plant fan power consumption. The separation efficiency of our classifiers has also been further increased. Of course, we are not only looking at the mill itself, but also at the complete grinding plant. Thus, pressure losses have also been reduced in our compact grinding plants by further optimising the ducting. These are just a few examples of activities that save further energy and thus also resources in general, since fewer raw materials have to be used, which only underlines the fluid relationship between efficiency and sustainability. Loesche The cement industry has gained ever-greater public interest due to its high CO2 emissions. At the same time, the availability of supplementary cementitious materials with comparatively low CO2 footprint (such as fly ash and slag), which have so far been used for cement production, has dropped significantly, especially in Europe. Calcined clay is attributed to have the potential to fill this gap to some extent. The optimal pre-treatment and grinding of

calcined clay will be an important task for the years to come. There are also the first plants grinding inert materials like granite. This of course places much greater demands on the grinding mills. Inert materials are more abrasive, and the cement mixture must be ground to a higher fineness to achieve satisfying product qualities, like good strength development. This results in an increase of requirements regarding the variability and flexibility of the grinding systems, in addition to the existing demands of best possible energy efficiency and availability. Vertical roller mills (VRMs) show good results in all areas and are known as the grinding system with the best product variability. There are grinding plants producing six different mixtures on one single Loesche vertical roller mill. thyssenkrupp Industrial Solutions AG Over the years cement manufacturers have extended their product portfolios by offering larger portions of additive cements, containing, besides clinker, a bigger share of ground limestone, slag, pozzolana or fly ash. The continuous reduction of clinker is also increasingly required in order to reduce the industry’s CO2 footprint. As a consequence, the fineness of cements with high additive content needs to be increased in order to maintain comparable cement properties. Hence, within cement grinding plant projects, companies’ aims range from achieving larger and larger throughputs to finer and finer products. The combination of different cement grinding systems is the key to coping with the challenges of grinding different types of cements. The Cement Technologies business unit of thyssenkrupp Industrial Solutions AG (tkIS) offers state-of-the-art grinding systems as well as common ball-mill grinding plants to serve specific customer needs: f High-pressure grinding roll polycom®: This machine has the lowest possible specific power consumption, which reduces total energy costs and the CO2 output. Especially, in conjunction with a ball-mill, the combi grinding system is an attractive solution regarding OPEX and CAPEX. No water spraying system is needed, but the machine offers a lower drying capacity than other grinding systems. f The vertical roller mill quadropol® incorporates a compact plant layout and is often used for moist raw materials. Due to its flexibility in grinding different cement raw materials and the fact that high throughputs can be realised, these grinding circuits are popular with customers, even though they require big gear boxes and a re-welding of the grinding rolls from time to time. f The polysius® booster mill is an agitated bead mill and is advantageous for producing high

World Cement April 2021

fineness cements. This fine grinder was recently introduced to the cement market. It is also an attractive solution for upgrade projects at existing cement works. As cement producers are under constant pressure to reduce OPEX too, it is also important to ensure the right cement quality by using the best available laboratory equipment. Therefore, tkIS has developed different polab® systems, which work in conjunction with XRF, XRD and laser granulometry. The newest development is the calorimeter polabCal®, which serves with immediate reactivity data of clinker and cement on pace together with regular process control data. It is now possible to adjust reactivity during production, which helps cement manufacturers to reduce their OPEX.

2) What factors should be considered by cement manufacturers when making the choice between different types of mill? FLSmidth When choosing a new mill there are several key considerations: f Capital investment. The total equipment cost for a ball mill remains lower than a VRM. However, the VRM with integrated separator has a more compact footprint, which provides civil/structural cost savings compared to the ball mill. This is particularly relevant in markets with high construction labour costs. f Feed materials. The physical characteristics of the materials being ground – e.g. abrasiveness or fineness – affects which mill is chosen. In addition, if frequent changes to the material characteristics are expected, that also needs to be considered. For most situations VRMs have an advantage with regard to material properties because they have more operating variables that can be adjusted. However, when material is too fine to make a stable grinding bed in a VRM, a ball mill is the more practical solution. If multiple products are being made in one mill, VRMs are the best option due to the short retention times, which allow a faster transition from one product to another. VRMs are also the preference for feed materials with high moisture content. f Maintenance. With a high emphasis on capacity utilisation and Overall Equipment Efficiency (OEE), it is of the utmost importance that the machines are easy to maintain with low maintenance time. With heavy emphasis on ease of maintenance in the past decades, the perceived maintenance burden of VRMs has been significantly reduced. f Energy efficiency and long-term total operating cost. VRMs consume 30 – 50% less power than ball mills, which can amount to millions 22

of dollars/euros per year. More importantly, the broader sustainability impacts have to be considered. These assets last 40 – 50 years. With the cement industry targeting net zero carbon emissions over the next 30 years, installing any equipment that is not in line with this means either the investment life will be shortened, or manufacturers will have to overcompensate later. Gebr. Pfeiffer Compared to other grinding systems, VRMs are characterised by lower maintenance and operating costs. This has been supported by cement producers and has led to vertical roller mills being a core component of modern cement plants today. There, they are used, for example, for grinding raw material, coal, pet coke, cement, blast furnace slag, limestone and pozzolana. The extremely short material dwell time also makes vertical roller mills much more flexible than ball mills when it comes to changing the proportion of the feed material or the fineness of the products. By changing the process parameters during operation, the mill is adjusted very quickly for each product mixture to achieve optimised performance. The Pfeiffer MVR vertical mill can be associated with the term ‘active redundancy’. The grinding rollers of the mill are actively redundant so production continues even if two of the up to six grinding rollers are swung out for maintenance. If the mill is equipped with a MultiDrive®, even individual rollers can be removed from operation. This is unique because here, as in other gearbox systems, in the MultiDrive, motors and gearboxes form several autonomous units. Each of these units can be removed from the system individually. So, it does not matter which component is under maintenance; the mill continues to operate. Numerous results from the field also show that the MVR vertical roller mill in particular is characterised by smooth running. This is due to its design and can therefore be seen across the product range. This low vibration level further increases the availability of Pfeiffer grinding plants and also enables trouble-free production of ultra-fine products. For example, a CEM I with a specific surface of 5500 cm2/g (acc. to Blaine) is being produced in a MVR vertical roller mill in Brazil. These high-strength cements allow for a reduced proportion of cement in the concrete or significantly smaller concrete parts, while maintaining the same loading capacity. Ultra-fine products are also produced with MVR mills for other industries. For example, limestone powder finer than 20 µm is also produced in a plant in Germany with such a vertical mill. Loesche Vertical Roller Mills for cement raw material, coal and cement are superior to ball mill grinding in World Cement April 2021

every respect. At comparable investment costs, the OPEX costs are decisive in the selection of the grinding system. Savings in electrical energy consumption of VRMs are in the order of 40% and VRMs are also significantly cheaper in terms of wear and maintenance costs. The trend is clearly toward cements with the lowest possible clinker content and greater flexibility, as the market demands an ever-increasing number of different cement types. The best suitable grinding system needs to allow product changes as quickly as possible and with minimal hassle. These preconditions are easily achieved when using a VRM system for cement grinding. The Loesche VRM system ensures that production can be quickly changed from simple OPC cement to composite cements, from low Blaine values to high Blaine values – an impossible task for ball mills. thyssenkrupp Industrial Solutions AG The right choice for a cement grinding system depends on individual customer requirements, which are always related to specific site conditions and to their local markets to be served, for instance, the type and number of different cements to be ground and individual product quality characterised by compressive strength (early and final), setting time, workability, water demand, and product fineness. Furthermore, the material compositions as well as the feed material properties (grindability, wear rate, moisture content) and other operational aspects like total specific power consumption of the grinding plant, product flexibility and maximum envisaged throughput rates have a big influence on the process design. It is important that cement manufacturers carry out an analysis of the incurred CAPEX and OPEX costs as well as consumables, spares, maintenance and labour costs, before making a decision regarding which cement grinding system should be installed.

3) What steps can be taken to ensure high separator performance? FLSmidth Performance comes down to the inherent design of the separator and the condition of its internal parts. The mechanical dimensions and geometry of the separator parts are all critical in achieving good separation efficiency. Separator designs are validated using engineering tools like CFD. This helps to ensure proper mixing of gas and material streams and maintain the velocity profiles as mentioned earlier. In addition, the developing use of different feed components as part of sustainability efforts increases the potential range over which separators need to work. To ensure performance under these conditions, installing drives with higher power and April 2021 World Cement

a wider range of operating speeds increases the flexibility of the mill system. It is equally important to maintain the mechanical reliability of a separator to sustain performance over the long term. This means balancing the mechanical dimensions with their influence on the wear rate of critical components. Internal velocities – and therefore wear rates – must be within a manageable range. If the critical internal parts, such as air seal or static guide vanes, wear too quickly they will immediately degrade separator performance. Of course, wear is a part of the comminution and separation process. Eventually, parts wear. It is important to replace them in a timely fashion. This is aided by making maintenance faster and easier through design features such as easy access, appropriate inspection and maintenance doors, and the possibility to replace specific wear prone parts alone. And in cases where material is more abrasive, additional wear protection or use of advanced materials can extend component life for the full production schedule. Gebr. Pfeiffer Through the installation of a high efficiency classifier, the differences in particle size distribution (PSD) between ball mill and vertical roller mill are neglectable. In a vertical roller mill, the PSD can be adjusted by different parameters: for example, by increasing the working pressure, the quantity of fines can be increased. By decreasing the volume flow, the PSD becomes wider. The design principle of the classifiers is always the same irrespective of their sizes. However, the sealing of the gap between the separating rotor and classifier housing can be adapted to suit the envisaged product fineness and oversize product required. The standard design for a ‘normal’ product fineness, as required in the cement industry for example, is a defined annular gap between the upper flange of the separating rotor and three-part wear ring on the classifier housing. Depending on the classifier size, the precise adjustment of the axial and radial gap dimensions is carried out while setting up and commissioning the grinding plant. When doing high fineness classification, seal air is directed onto this annular gap as an additional means to avoid any oversize in the finished product. This seal air feature is used mainly when grinding materials like limestone to very high fineness such as less than 0.1% residue on 20 µm. In some applications, the production of coarser product fractions can be lucrative in addition to the fine end product. By providing a variable speed grit discharge screw conveyor it is possible to simultaneously produce e.g. fine limestone meal as well as grits of sizes up to 1 mm. Such a grinding plant with a Pfeiffer vertical mill and high efficiency classifier of the type SLS is operational in Poland. The fine material, which is the main product, is 23

separated from the gas flow in a bag filter and stored in silos. The discharged classifier grits are separated at 0.1 mm in a downstream Pfeiffer distribution table separator of the type SUV for screening in a three-deck screening machine at 0.4 mm, 0.8 mm and 1.2 mm. These products are then stored in separate silos. Any off-size from the screening and separating stages that is classified as undesirable for marketing reasons can be returned to the mill so that no material has to be discarded. The infinitely variable control of the screw conveyor speed allows a production ranging from 0 to 55% of classifier grits of a defined grain size. Using two-phase CFD, the direction of flow in the separator, the differential pressure and separation efficiency can be optimised very well.

distribution though pipes, filters, and cyclones, which also reduces wear. f Additional steps: It is important to supply enough separation air. By reducing the cage area of the separator, the air velocity and thus the energy for the separation process is increased. The equilibrium of forces such as the drag force created by air velocity, and gravity force created by the rotation speed of cage, have to be maintained. In the case of very fine product, the use of bag filter discharge is recommended instead of cyclones.

Loesche We see three main steps: f Modern simulation and test methods as well as the consideration of practical experience from hundreds of successful customer projects over decades enable the permanent procedural enhancement of separator performance. f Continuous mechanical and design ameliorations make it possible to optimise investment, operation and maintenance costs and to achieve a higher durability of the machines. f Matching of the separator-mill-unit with other components of the grinding plant has the following effects: a compact design reduces investment costs and a higher efficiency of further plant and production processes decreases the operational costs.

FLSmidth Modular grinding systems are most commonly used for small capacity grinding stations and new grinding lines to achieve small capacity increases, typically up to 500 000 tpy. The biggest advantages are in the construction or installation cost savings. Truly modular grinding systems, where the plant equipment is preinstalled in structural elements with all utilities (air, water) and electrical wiring done ‘in the shop’ before shipping to site, can be installed in much less time than traditional plants. The shorter installation time also means a faster journey to production, which can be critical in meeting the needs of rapidly developing markets. Modular grinding systems also have the potential to be relocated from one site to another more easily than conventional installations. While this is typically a secondary consideration, there are some circumstances where it has particular benefits, for example in regions where multiple small isolated markets are expected to develop over a period of several years.

thyssenkrupp Industrial Solutions AG f Adjustable guide vanes can be used to increase the energy level of separation: The design of the new guide vanes has been optimised for best flow pattern, and minimised wear, and enables the operator to adjust the separating gap between the edge of the guide vane and the outer edge of the rotor in a specific range. The separator performance is increased due to the better dispersion of agglomerates within the flow pattern outside the cage rotor. f By installing a swirl breaker, pressure drop can be decreased: A dynamic separator needs swirl to generate centrifugal force. The rotation of the air in the separator rotor shows a flow profile in the form of a vortex. However, as soon as the fines have passed the rotor blades, the swirl inside the cage loses its procedural benefit. The swirl breakers slow down the rotational vortex, ensuring flow alignment, and lower tangential speeds. There is the same angular velocity at every point of the radius. This causes an even distribution of the outflowing air and a more even

4) What advantages do modular grinding systems offer over more conventional set-ups?

Gebr. Pfeiffer We can only speak for our own ready2grind system which has proven itself in the field worldwide. It has fewer options than a traditional mill but can still offer efficiency, sustainability and reliability. This range was developed in response to market demand. After the financial crisis of the late 2000s, there was a realisation that there was severe clinker overcapacity across the industry. At the same time, there were still several markets with relatively weak infrastructure that were natural homes for small grinding plants of 20 tph. Now these too have moved to larger capacities to save on capital expenditure as much as possible, albeit in a lower ‘capacity window.’ The ready2grind 1800 produces 22 – 34 tph, the ready2grind 2500 produces 52 – 79 tph and the ready2grind 3000 producess 59 – 90 tph. These grinding plants are well suited for remote areas or for instances where cement production needs to

World Cement April 2021

ADVANCED PROCESS CONTROL INNOVATIVE MEASUREMENTS

KILN SHELL COOLING ON THE SPOT

WITH KILNCOOLER

INFRARED CONTROLLED WATER COOLING OF KILN SHELL – – – –

expansion of kiln‘s operation time reduced mechanical tension fast, but carefully cooling down energy savings

THAT‘S WHAT WE CALL THE KIMA PROCESS.

WWW.KIMA-PROCESS.DE

be very close to the cement consumer, even if the infrastructure is challenging. There needs to be a high degree of prefabrication built in at the design stage so that units can be installed. Using the ready2grind range, we have worked with clients that are not traditional cement producers but rather traders and construction companies. For them, the speed with which the project can be completed is often very important. This is another driver towards a modular, pre-fabricated approach. A further advantage of these systems is that the containerised plant components can be transported and installed more easily. Our references demonstrate that we have also implemented our clients’ requirements well in the field of modular systems.

layout, and procurement packages. The modular plant offers a very competitive solution with a low EPC price, short delivery time, easy installation and low maintenance. Modular grinding plants are allowing customers and even newcomers a fast entry into cement markets. Beside the low CAPEX with shorter payback periods, the modular concept bears low technical or financial risks for customers. Modularisation also facilitates the dismantling and re-erection of the grinding plant elsewhere, if commercial or market conditions change. The polysius modular grinding plant ensures the quality and reliability of all equipment and maximises the performance of the plant, producing a high cement quality.

Loesche Loesche has created a modular system for complete grinding plants for all cement mill sizes available from the LM 24.2 CS to the LM 72.4+4 CS. This modular concept enables a fast and still very flexible design of the grinding terminal. For example, the product storage capacity can be individually adapted to the needs of the customer. The grinding plant can be adjusted optimally to all topographical areas. Most of the modules for smaller terminals contain completely pre-assembled container systems which, depending on their use, can also be used in larger mills. Particular focus was placed on quick assembly and good maintenance options, so that access to all maintenance points is given. The decreased installation and engineering times reduce the overall time schedule. Therefore, the grinding terminals can go into production sooner in comparison to a plant not using a modular design. This modular concept is suitable for grinding terminals in greenfield as well as brownfield projects. The advantage of the reduced overall project times and the earlier start of production also come into play here.

5) What role do you see for digital technologies, such as process automation solutions, in the grinding sector?

thyssenkrupp Industrial Solutions AG For years, the cement market has been volatile and with regard to grinding plants, there has been an increasing demand for fast installations, (semi-) mobile solutions and for closing white spots. The market is still driven by a decreasing CAPEX trend, new entrants, higher competition and less engineering capacities at clients’ project engineering teams. All these market drivers are met by the concept of modular grinding plants. This concept is ideal for capturing markets of up to 500 000 tpy, is suitable for greenfield or brownfield projects and offers several advantages compared to a conventional tailor-made grinding system. It is based on a stripped-down concept, which focuses on the core needs of the operation with optimised costs and less engineering, is fully standardised and incorporates pre-engineered equipment, plant

FLSmidth Integration of digital technology is already a proven part of grinding solutions. FLSmidth has offered advanced control through ECS/ProcessExpert® for 20 years. Today, it has been proven to increase overall system performance, lower power consumption, and maintain better quality control (lower standard deviation). Those same benefits apply particularly well to the development of ‘green cements’ with a lower clinker factor. Taking advantage of IOT capability, the ‘newest’ digital offerings are in advanced, predictive maintenance or online condition monitoring services (CMS). These services have been offered for critical components such as gear reducers for many years. Allowing suppliers to monitor the mechanical condition of these critical parts of the mill system helps to prevent unplanned and costly stoppages or breakdowns that result in significant lost production and revenue. The latest condition monitoring services integrate process operating variables and mechanical sensor readings, along with the use of advanced predictive modelling based on large data sets that inform when adjustments are needed to mechanical settings or identify when maintenance of critical parts will be needed. The result is improvement in overall performance from equipment optimisation, but more significantly reduced maintenance cost from better planning and less interrupted production time. Another aspect of digital technology that has been highlighted during the COVID crisis is the increased ability to provide remote services. Availability of historic operating data and long-term monitoring of critical KPIs make it much easier and faster to provide troubleshooting and operating support to plants, independent of location. There are also cost savings from the elimination of travel and on-site

World Cement April 2021

service costs for issues that can easily be resolved remotely, saving the budget allocation for more complex (and often more costly) issues. Gebr. Pfeiffer Digital technologies in cement grinding are not the future, they are the present. We have followed the Industry 4.0 trend since it became a feature of the sector. It drives our clients and so it drives us. We offer several digital products, one of which is GPlink, which saves sensor data for data analysis and enables 24/7 access to data from mobile devices around the world. When transmitted to the company’s service team, a solid basis for support and rapid, targeted assistance is given. GPlink forms the basis for all other digital products. The modular GPpro is the logical continuation of digitalisation. GPpro enables, for example, an advanced maintenance system, with maintenance according to actual need and not according to fixed intervals. The system also includes additional sensors and offers modules for data analysis, reports, optimisation with the help of artificial intelligence (AI) and many other resource-saving optimisations such as dynamic water injection. The topic of AI is particularly exciting because the benefits are clear. A skilled human operator can certainly set several operating parameters and overlook the interaction of these. With the help of artificial intelligence, any number of parameters can be examined and the ideal setting values for an application can be determined. There is enormous potential here and the first results with an industrial mill have been very promising. Digitisation is progressing and we are following this path. There is also a lot of movement in this area and Gebr. Pfeiffer attaches great importance to this topic. Loesche For the plant operator, maintaining international but also regional competitiveness is crucial. Therefore, the comminution technology must be permanently optimised in terms of efficiency, performance, and energy consumption. The systems required for this increase in complexity with the growing demands on, for example, mixed cements in terms of water requirements and strength. Loesche has long been committed to developing solutions and machines that are as environmentally friendly and resource-saving as possible. Digital technologies are absolutely necessary in order to achieve these goals more quickly and to be able to consistently develop the goals further. At Loesche, we do not limit ourselves to computerisation and connectivity, but apply self-learning software for process optimisation that provides forecast data and operating settings in real time in order to operate the grinding technology at the limits of its physical possibilities – stably and reliably. In conjunction with

April 2021 World Cement

diagnostic systems and service platforms for spare parts procurement, this results in the possibility of implementing condition-oriented maintenance and servicing strategies. A holistic picture emerges to support plant operation. thyssenkrupp Industrial Solutions AG Digitalisation is the connecting element between the process know-how of the suppliers, and the needs of the cement producers. Suppliers can benefit from accessing the data for process and machine optimisation and cement producers can achieve higher outputs, less energy consumption and higher plant availability with more reliable plant operation. Today, this is possible as grinding plants are equipped with sensors to control the process and the plant equipment. The data from these sensors is collected and can be displayed on the dashboard in the control room for interactive real-time insights. The KPIs of the grinding plant can be visualised and by identifying anomalies, characteristic patterns and operational conditions, the plant operator can gain a more transparent view about the performance of the grinding plant. By installing an artificial neural network together with optimisation algorithms, recommendations on plant operation can be provided to the operator. The intelligent model advises optimal set-points for process parameters in order to maximise targets for throughput and energy consumption, enabling the operator to enhance the plant efficiency and reduce the operating costs. In addition, remote assistance services by tkIS in combination with predictive maintenance or root cause analysis offer the possibility of increasing the availability of all machines from the grinding plant. A proper and timely supply of spare parts can be organised and maintenance work can be planned better in order to maximise plant availability.

6) Looking to the future – what do you see as the next steps in terms of grinding technology? What advances can we expect to see over the coming years? FLSmidth Grinding technology has reached a stable point in the lifecycle curve. Incremental improvements are most likely to account for advancements for the near future. These will be in the areas of: f Wear materials and metallurgy that allow for longer lasting and smaller/lighter component weights. f Integration of digital technology to push the limits of efficiency and performance higher, while implementing predictive maintenance to streamline costs for labour, and parts supply and inventory.

f Continued optimisation of the production of blended and high Blaine cements and the introduction of new high-performance cements that use a wide range of SCM to replace clinker. This includes advancement of separator designs to achieve finer product residues at higher capacity than are possible today. More significant advancements will likely come over the long term, as research into energy consumption and grinding mechanisms is developed into new applications. Gebr. Pfeiffer Sustainability will be one of the central challenges, because cement production is responsible for 8% of global carbon emissions which is why dependency on fossil fuels must be reduced. Therefore, the use of modern and highly efficient technologies with low electrical energy requirements is indispensable, especially in the cement industry. Around 60% of the carbon dioxide emissions in cement plants are released during the limestone calcination process. As carbon is produced here as a by-product of a chemical reaction, this carbon dioxide emission cannot be reduced by alternative fuels or a higher efficiency of the calcining plants. The obvious solution is therefore to reduce emissions by using clinker substitutes or a higher proportion of additives, as this simply means that less clinker has to be produced and the clinker factor can be reduced tremendously. The MVR is a versatile system for many feed material applications and can be adjusted easily for all different kinds of clinker replacement materials. With features like a heated rotary lock for moist feed materials or when feeding dry and fine materials, an additional feeding point at the classifier housing the MVR mill is prepared for a wide range of clinker replacement materials. Our task as a grinding plant manufacturer is to provide the appropriate solutions for the changing challenges of the industry in order to reduce the carbon footprint in cement plants, protect our environment and at the same time give our customers a competitive advantage. Gebr. Pfeiffer continues to put innovation into practice and subjects its efficient mills and the associated processes to consistent, continuous improvement processes. Our MVR mills have a high power density and produce cements of the broadest range of material compositions. Their comparatively low energy consumption saves resources which is good for the environment and the wallet. This is complemented by a wide range of digital products and services. Loesche A disruptive grinding technology for mass products like in the cement industry is not in sight. In fact, the

already established grinding systems (VRMs, HPGR and ball mills) will still be present on the market, with the energy efficient mills having an advantage. However, the trend towards high-throughput grinding plants, as experienced in the last two decades, will come to a halt. In contrast, the demand for smaller modular grinding terminals with manageable investment costs and fast production starts will further increase. Due to the market situation, the cement industry will put a stronger focus on the modernisation and optimisation of existing plants. Optimisation of grinding plants will also be possible by means of increasingly well-functioning self-learning expert systems using potentials for productivity improvement. Digitalisation acts as a driver for technical innovations and is a touchstone for the innovative strength of leading manufacturers in plant engineering. thyssenkrupp Industrial Solutions AG Along with increasing demand for pre-cast concrete, other high early-strength cement types, and low clinker cement, there will be a demand for finer grinding. One solution to achieve the necessary cement quality – and partially also to compensate for loss of capacity due to a higher fineness – is the polysius booster mill, a horizontal agitated bead mill. Rotating discs with mounted grinding tools rotate at high speed inside a fixed shell, stirring the small balls (beads) and creating a ‘cloud’ of beads and material. This mill, established for decades in wet processes, has been jointly further developed by companies Netzsch and thyssenkrupp Industrial Solutions AG to be applied in dry processes for very fine grinding of cementitious materials. The modular, compact and highly energy-efficient system can be integrated into an existing grinding plant. Results from a first reference, and from trials in a small-scale pilot plant, show that the clinker content of new cement compositions can be reduced significantly while maintaining previous – especially early – strength values. In other trials, ultra-fine cements were produced, achieving comparable quality even at lower fineness values. In terms of quality, another add-on to the solution, and to grinding plants in general, is a calorimeter, recently introduced by thyssenkrupp Industrial Solutions AG. Instead of only using fineness or residue values as indications for quality, this solution measures heat from the early hydration process, allowing for an accurate prediction of the final quality within minutes. It has been tested and proven as beneficial in several plants, showing potential for faster cement quality control in the future. Finally, in combination with process optimisations and the application of digital products at cement grinding plants, the polysius booster mill offers production opportunities for cement manufacturers worldwide.

World Cement April 2021

Emre Ergun, IEP Technologies, outlines the preventative and protective measures the company put in place to help a Turkish cement manufacturer mitigate the combustion risks associated with alternative fuels.

he use of refuse derived fuel (RDF) is becoming increasingly common in heavy industries and power plants where it is viewed as a more sustainable alternative to fossil fuels. RDF is typically a solid fuel, produced from industrial, municipal or commercial waste, which after screening and separation is shredded or pelletised in order to provide a suitable alternative fuel.

One such example of RDF usage is within the cement industry, where it is used to fire kilns. However, in spite of the environmental and cost advantages achieved, systems for preparing and transporting this type of fuel are exposed to the dangers of industrial fires and explosions. Careful planning and design therefore are vital in plants where RDF is used.

Industrial fires and explosions can occur in many manufacturing processes when fine particulates, dispersed in air, are subjected to an ignition source within a contained environment – for example a duct, vessel, or collector. Ignition can be generated by many different factors,

Various types of raw material used for the preparation of refuse derived fuel.

Various types of raw material used for preparation of Refuse Derived Fuel (left) and Refuse Derived Fuel material storage area (right).

including hot surfaces, burning embers, flames, welding, spontaneous combustion, friction or uncontrolled electrostatic discharges. These ignition sources can be minimised or eliminated by a combination of effective engineering controls, safety management and operator awareness, but in many cases, the explosion risk is ever present and therefore techniques to mitigate the potentially catastrophic effects must be employed. It was against this backdrop that a major cement manufacturer located in the western part of Turkey recently made a multi-million euro investment in a system to allow the use of alternative, RDF and related Tyre Derived Fuel (TDF) in its process to reduce its operating costs and improve its carbon footprint. In order to achieve the maximum benefits from the company’s reduction targets, the system consisted of several elements, including an RDF preparation plant and semi-closed material storage warehouse, as well as RDF and TDF transportation systems. Another key consideration for the company was the flexibility of producing its own RDF as well as utilising third party supplied TDF and RDF within its process. The RDF preparation process included the following items: material acceptance pit, front-end loader fed open top primary shredder, metal separation, air-material separation, and a connected secondary shredder where all material transport between processes was to be carried out using closed conveyors. Additionally, an externally located dust collector was to be used for dedusting of the process. RDF fuel prepared at the plant was then to be kept in a storage warehouse where the material was to be fed to the cement kiln using a series of conveyors and chutes.

The challenge

Broken shredder knives – a potential ignition source inside primary and secondary shredders. 30

At the outset, the company’s Operations and Health and Safety Group decided to only use solid wastes such as shredded tyres, paper/packaging wastes, oil/solvent contaminated textiles, dried sludge, and plastic as its alternative fuel source. Due to their variability, the explosibility and ignitability hazards of these materials are not well known and are difficult to quantify. A data and literature review conducted on the various materials that can potentially be introduced to the system indicated that such material may become easy to ignite, especially if mixed with solvent wastes. Furthermore, explosion risks are also created by fibres and dusts suspended inside the enclosed process equipment such as shredder enclosures and chutes. Additional risks from the unintentional inclusion of discarded aerosol cans to the shredding system were identified; these could World Cement April 2021
